Guangzhou Niceway Electronic Technology Co., Ltd

Printer Specifications

Print Method                                                   Thermal Transfer / Direct Thermal

Print Resolution                                              203 dpi

Print Speed                                                      2~6 inch/s (51-152mm/s) Print Width                                                                     Max. 104mm (4.09") Print Length                                                                     Max. 2286mm (90")

Dot Density                                                     203dots/inch (8dots/mm)

Dot Size                                                           0.125x0.125mm (1mm=8dots) Print Head                                 50KM

Interface                                                          USB+Parallel+Serial (USB+Bluetooth or USB+WiFi can be optional) Physical Memory SDRAM: 8MB, FLASH: 4MB

Media Sensor                                                  Reflective and Transmissive Sensors (adjustable) Command set       Standard TSPL emulation, ZPL emulation optional

Media Characteristics

Media Roll OD                                                127mm (5")

Media Type                                                     Continuous, black mark, gap, punched hole, Fan fold and more labels

Media Rolling Up Method                               Printing side outward rolling

Media Width                                                   Max.120mm (4.72")  Min.20mm (0.78")

Media Thickness                                             Max. 0.254mm (10mil)  Min. 0.06mm (2.36mil) Media Roll Core Size 25.4mm~38mm (1"~1.5")

Media Gap                                                      Min. 2 mm (0.09")

Label Length                                                    10~2286mm (0.39"~90")

Ribbon Characteristics

Ribbon OD                                                      Max.67mm

Ribbon Length                                                 Max.300m

Ribbon Core Size                                            1 inch (25.4mm)

Ribbon Width                                                  Max.110mm, Min.30mm

Ribbon Rolling Up Method                             Outward Rolling

Auto Cutter

Cutting type                                                     Full cut or tear off

Cutting Media Thickness                                 0.06~0.25mm

Service life                                                      1.5million cuts

BarCode/Fonts/ Graphics

Symbologies

Enlargement&Rotation                                    1 ~10 times enlargement in both directions; 0°、90°、270°、360°rotation

Character Size                                                 Font 0 ~ font 8

Code39, Code93, Code128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-13, EAN-14, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI,

1D Barcode                                                     PLESSEY, POSTNET, china POS, ITF14

2D Barcode                                                     QR code

Graphics Processing                                        Support BMP/PCX/BAS files

Editing Software                                              Nicelabel SE

Operating Characteristics

Power supply                                                  Input: AC 110V/240V   Output: DC24V/2.5A, 60W Operation Condition         Temperature: 5~45℃(41~104℉), Humidity: 25~85%RH

Storage Condition                                            Temperature: -10~50℃(-10~140℉), Humidity: 10%~90%RH

Physical

Characteristics

Printer Dimensions                                         278x210x175mm (WxDxH)

Printer Weight                                                 Approx. 2.1KG

Accessories

External Media Holder                                    Optional

Auto Cutter                                                     Standard
